Pyramid Peak

SLEEPS
2 – 4

TOTAL SQFT
250

LENGTH
24′

WIDTH
8′ 6″

What You'll Love About the Pyramid Peak

This 24-foot home may be the perfect fit for you. As you enter through the side entry, you will be greeted with a spacious studio-style layout, featuring five of our signature 80-inch windows. An optional endwall transom picture window can also be added as a finishing touch.

The optional chunky edged snackbar/table serves as a great workspace for hobbies or dining with friends. The entry closet space includes room for a single unit washer/dryer, adding an extra level of convenience. The galley kitchen includes another 80-inch window, a standard 2 burner cooktop, with an optional range, an apartment-sized stainless steel refrigerator, a stainless steel deep sink, and ample counter space, making it an extremely functional space.

The single loft, with ladder access, provides additional storage or sleeping space. The 5-foot open bathroom includes a full 60-inch one piece shower, with optional roll-in feature or tub/shower options available. Grab bars and a handicap toilet can easily be added, offering excellent flexibility for many situations. If you have specific needs, please don’t hesitate to discuss them with our knowledgeable staff.

Gallery

Tour the Pyramid Peak

Video Tour

Follow us on a video tour of the interior of our modern and luxurious Pyramid Peak model.

Floor Plans & Key Details

House Length (Exterior)
24′
Total Sqft
250
Main Level Sqft
201
Primary Loft Sqft
49
Secondary Loft Sqft
–
Interior Height
10′ 8″
Height Under Loft
6′ 6″
Loft Height
48″
Exterior Height
13′6″
Exterior Width
8′6″
Sleeps
2 – 4
Base Price
$84,390

Specifications

  • Trailer: Heavy-duty tubular steel, custom-built for each home. Includes all braking axles, with “D” ring tie downs, corrosive resistant automotive finish, and four corner mounted heavy duty leveling scissor jacks.
  • Front and rear endwall 6” overhangs
  • Eaves: Front door side and back sidewall standard in 9’6” widths, Optional 8’6” models.
  • Floor: 1-1/8” T&G plywood decking
  • Siding: Residential LP Smart Panel (50-year warranty) with rough-sawn trim
  • Exterior: Whole house wrap
  • Flashing: Flashing of all windows
  • Insulation: R-15 walls and ceiling, R-15 in floors
  • Windows: High-efficiency dual-glazed, vinyl, Low-E, argon gas residential windows. Sizes vary per model, most plans include 80” tall windows.
  • Roof: Durable standing seam metal (40-year warranty)
  • Porch Lights: Switched exterior porch lights at all exterior doors
  • Exterior Door: Insulated with a deadbolt and peephole.
  • Door Hardware: Brushed Nickel
  • Exterior Outlet: 1 standard
  • Holiday lighting: 1 exterior outlet switched
  • Walls & Ceilings: Residential smoothwall with white painted finish throughout
  • Trim Package: 3” baseboard and 2 – ½” window trim throughout
  • Flooring on the Main floor: Luxury vinyl plank
  • Flooring on Lofts: Beautiful clear coat poly finished tongue and groove pine
  • Ceilings below lofts (except baths): Beautiful clear coat finished tongue and groove pine with exposed finished 4×4 beams
  • Cabinets: White shaker style – Base cabinets with drawer over door design where possible and full-depth ball-bearing drawer guides throughout with adjustable shelving and soft close feature.
  • Overhead cabinets include adjustable shelving. Extended height overheads are floor plan-specific.
  • Countertops: 36” tall – Laminate w/ 6” white subway tile backsplash
  • Optional cabinets include Snack bars, Custom pull-out leaf tables, loft storage cabinets, wine cabinets, bookshelves, and hang-up closets- where applicable.
  • Kitchen Sink: 24” stainless steel top mount minimum 8” deep
  • Faucet: Satin nickel single lever, gooseneck pullout style
  • Passage doors: White w/ satin nickel hardware
  • Loft Ladder: 1 standard w/ mounting hardware. Pine – clear coat finish.
  • Optional staircases and custom ladders are available.
  • Lighting: LED wall sconces and can lighting with floor plan-specific track lighting over the kitchen sink
  • Electrical Receptacles: Residentially spaced and included in loft areas
  • Water Heater: Tankless propane – RV type 2.1 GPM
  • Refrigerator: Apartment-sized stainless steel 9 CF. Plans noted with under counter are 3.1 CF.
  • Heating: Electric convection heater w/thermostat
  • Cooktop: Electric 2-burner or propane – Black
  • Range Hood: Vented to exterior 24” – Black
  • Fresh Water Lines: Durable PEX w/ shutoff valves to sinks and toilets
  • Fresh water RV-type connection w/hose-type fitting.
  • Drain Lines: ABS w/ slide valve
  • Electrical Service: 50 amp 220 Volt including a 25’ weather resistant power cord
  • Ceiling Fan Prep: Wire and brace for ceiling fan
  • Loft Light Switches: 3-way light switches to each loft
  • Detectors: Carbon monoxide and smoke detectors
  • Fire Extinguisher: Included
  • Propane Hookup: Includes easy connect regulator
  • Most units prepped for RV washer/dryer 110 Volt
  • Mini-split system electrical prepped for 110 V
  • Shower: One Piece Fiberglass, Sizes are floor plan specific
  • Toilet: Residential, China, ceramic white round bowl
  • Sink: White china with base cabinet
  • Medicine cabinet: Beveled edge mirrored
  • Faucets: Dual knob brushed nickel finish, shower, and sink
  • Ventilation: Switched exhaust fan
  • Baths include an electrical outlet behind the toilet for future composting toilets.
